GHB3040I - Eaton 40A 3-Pole 480Y/277V Molded Case Circuit Breaker G-Frame

GHB3040I

GHB3040I is a three-pole molded case circuit breaker manufactured by Eaton for use in distribution panels and switchboards. This G-frame breaker provides thermal-magnetic trip protection at 480Y/277 Vac and 125/250 Vdc ratings with 50/60 Hz frequency compatibility. Key Specifications

• Amperage Rating: 40A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Number of Poles: Three-pole
• Frame Size: G-frame
• Circuit Breaker Type: Molded case
• Trip Type: Thermal-magnetic
• Interrupt Rating: 14 kAIC at 480Y/277 Vac; 65 kAIC at 240 Vac
• Frequency Rating: 50/60 Hz
• Certifications: UL Listed
• Series: Series C

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GHB3040I
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 40
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 782114312346
• GTIN : 00782114312346
• Country of Origin : Dominican Republic
• Dimensions : 2.875 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.45
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 543
• Certification : CSA Certified, UL Listed
