GHB3030I - Eaton Series C Type GHB 30A 480Y/277V 3-Pole Molded Case Circuit Breaker

GHB3030I

GHB3030I is a Series C Type GHB molded case circuit breaker designed for bolt-on panelboard mounting in three-phase four-wire distribution systems. This 30-ampere, three-pole breaker features non-interchangeable thermal-magnetic trip protection and is rated for 480Y/277 Vac or 125/250 Vdc operation. The G-frame design provides reliable protection with an interrupt rating of 35 kA at 240 VAC and 14 kA at 480Y/277 VAC.

• Amperage Rating: 30A
• Voltage Rating: 480Y/277 Vac, 125/250 Vdc
• Number of Poles: Three-pole
• Frame Size: G-frame
• Mounting: Bolt-on
• Trip Type: Non-interchangeable thermal-magnetic
• Interrupt Rating: 35 kA at 240 VAC, 14 kA at 480Y/277 VAC
• Series: Series C
• Certifications: UL Listed
• Weight: 1.75 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: GHB3030I
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 782114312339
• GTIN : 00782114312339
• Country of Origin : Dominican Republic
• Dimensions : 2.875 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.45
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 534
• Certification : CSA Certified, UL Listed
