GHB3025S1 - Eaton 3 Pole 25A 480VAC Molded Case Circuit Breaker, Bolt-On, Shunt Trip, 14kA Interrupt, GHB Series, Thermal Magnetic Trip, UL Listed

GHB3025S1

GHB3025S1 is a 3-pole, 25A molded case circuit breaker from Eaton, designed for reliable protection in industrial applications.

This Eaton GHB Series breaker features a thermal magnetic trip unit, bolt-on mounting, and an integrated shunt trip device for remote operation. It is rated for 480VAC (277/480Y), 250VDC, and offers a 14kA interrupt rating at 480VAC. Ideal for machinery, fueling pumps, and panelboards, this UL-listed breaker ensures safety and performance in demanding environments.

Key Specifications
• Part Number: GHB3025S1
• Manufacturer: Eaton
• Amperage: 25A
• Voltage: 480VAC (277/480Y), 250VDC
• Poles: 3
• Mounting Type: Bolt-on
• Interrupt Rating: 14kA @ 480VAC
• Series/Frame: GHB
• Trip Unit: Thermal magnetic
• Special Feature: Shunt trip (120V operation, pigtail lead)
• Certifications: UL Listed
• Application: Industrial, machinery, fueling pumps, panelboards

At Essential Parts, we offer fast shipping, lowest price

Specifications

• Part Number: GHB3025S1
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : GHB
• Voltage : 480
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Terminal Connection : Screw Clamp
• Frame Size : 100/GHB
• Temp Rating : 28-158 ¡F (-2-70 ¡C)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 786679029428
• GTIN : 00786679029428
• Country of Origin : Dominican Republic
• Dimensions : 2.63 in x 4 in x 3 in (Length/Depth x Height x Width)
• Weight : 1.75
• Panel Type : Eaton Powerline Panelboards
• Standards : UL 532
• Certification : CSA Certified, UL Listed
