Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
FXD62B110L
FXD62B110L is a Siemens Sentron FD-frame molded case circuit breaker designed for industrial and commercial power distribution applications requiring reliable overcurrent protection at 600 volts AC.Key Specifications
- Amperage Rating: 110 Amps
- Voltage Rating: 600 VAC
- Number of Poles: 2
- Frame Type: FXD6
- Interrupt Rating: 22 kA at 600V
- Trip Unit: Thermal/Magnetic
- Mounting: Bolt-On with FX Lugs
- Frequency: 50/60 Hz
Specifications
- Part Number: FXD62B110L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : FXD
- Voltage : 600
- Amperage : 110
- Phase : 1
- Poles : 2
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : FD Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643005563
- GTIN : 00783643005563
- Country of Origin : Mexico
- Dimensions : 10.63 x 5.906 x 6.693 inch
- Weight : 8.62
- Certification : UL, CSA, IEC
