FH360601021 - Square D 60 Amp 600 Volt 3 Pole FH Frame I-Line Plug-In Circuit Breaker Thermal Magnetic

FH360601021

FH360601021 is a Square D 3 Pole, 60 Amp, 600 Volt molded case circuit breaker designed for I-Line style plug-in mounting with thermal magnetic trip protection.This FH frame breaker features a thermal magnetic trip unit with LI (Long-Time and Instantaneous) trip functions, suitable for power distribution applications. It has a high interrupting rating of up to 25kA at 480 VAC and 18kA at 600 VAC, with UL and CSA certifications. The breaker includes a 120/208/240 VAC shunt trip and supports wire sizes from 12 to 1/0 AWG aluminum and 14 to 1/0 AWG copper.

Key Specifications
• Amperage: 60 A
• Voltage: 600 VAC
• Poles: 3
• Frame Type: FH
• Mounting Type: I-Line Plug-In
• Interrupting Rating: 25kA @ 480 VAC, 18kA @ 600 VAC
• Trip Unit: Thermal Magnetic with LI functions
• Certifications: UL, CSA
• Includes 120/208/240 VAC Shunt Trip
• Terminal Wire Size: 12 to 1/0 AWG Aluminum, 14 to 1/0 AWG Copper
• Dimensions: 6" H x 4.5" W x 4.13" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with factory installed 120/240V shunt trip

Specifications

• Part Number: FH360601021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901076063
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6.449
