FH26060BC - Square D 60A 2 Pole 600V I-Line Plug-In Circuit Breaker Thermal Magnetic 25kAIC@480V

FH26060BC

FH26060BC is a 2 pole, 60 amp, 600V I-Line plug-in molded case circuit breaker designed for reliable thermal magnetic protection in commercial and industrial power distribution systems. This Square D FH26060BC circuit breaker features a high interrupting capacity of 25kAIC at 480V, making it suitable for demanding applications. It utilizes an I-Line style plug-in connection for quick installation and includes both long time and instantaneous trip functions for comprehensive circuit protection. The breaker is rated for use at 40°C and supports wire gauges from 14 to 1/0 AWG AL/CU.

• Manufacturer: Square D
• Series/Frame: FH
• Amperage: 60A
• Voltage: 600VAC, 250VDC
• Poles: 2
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 25kAIC@480V
• Protection Type: Thermal Magnetic
• Functions: Long Time and Instantaneous Trip
• Terminal Connection: Line and Load Lug
• Wire Gauge: 14 to 1/0 AWG AL/CU
• Temperature Rating: 40°C
• Certifications: UL, CSA, NOM, IEC, CCC, CE

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FH26060BC
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FH
• Voltage : 600
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 25kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901343301
• GTIN : 00785901343301
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 3 in (76.2 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6
• Certification : UL, CSA, NOM, IEC, CCC, CE
• Wire Size : 14 to 1/0 AWG AL/CU
