FDPWS322R - Cutler Hammer Type FDPW 240V 60A 3-Pole Fusible Panelboard Switch

FDPWS322R

FDPWS322R is a Cutler Hammer Type FDPW fusible panelboard switch designed for commercial, industrial, and service entrance applications to protect and switch feeder and branch circuits. This 3-pole, 60-ampere switch operates at 240 volts AC and features a panel-mount configuration with NEMA 1 rated enclosure. The switch accommodates Class R fuses and is UL-listed for reliable performance in distribution panelboard installations. With a maximum interrupting capacity of 200,000A rms symmetrical at 600V AC, this switch provides robust protection for demanding electrical systems. The unit measures 22.4 inches in length and is designed for horizontal mounting within PRL4-F or CDP/FDP distribution panelboard chassis. An interlock mechanism prevents unsafe operation and ensures optimal security during maintenance and switching operations.

• Amperage Rating: 60 Amps
• Voltage Rating: 240 Volts AC
• Poles: 3-Pole
• Fuse Type: Class R
• Mounting: Panel Mount
• NEMA Rating: NEMA 1
• Interrupting Capacity: 200,000A rms symmetrical at 600V AC
• Enclosure Dimensions: 22.4 inches L x 10.2 inches H x 7.8 inches W
• Connection Type: Branch
• Conductor Size: #14 AWG to 1/0 AWG
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDPWS322R
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Switch
• Item Subcategory : Panel Mount
• Family : Type FDP
• Type : FDPWS
• Voltage : 240
• Amperage : 60
• Phase : 3
• Poles : 3
• AIC rating : 200kA@240V
• Fuse Class : R,H,K
• Configuration : Single
• Switch Style : Fusible
• Nema Rating : 1
• Compatible Frames : SGHA

Product Data

• UPC : 782114289112
• GTIN : 00782114289112
• Country of Origin : Mexico
• Dimensions : 22.4 in x 10.2 in x 7.8 in (Length/Depth x Height x Width)
• Weight : 14.05
• Certification : UL Listed
