FDPWS323R - Cutler Hammer 100A 240V 3-Pole Fusible Panelboard Switch FDP Frame

FDPWS323R

FDPWS323R is a Cutler Hammer fusible panelboard switch rated for 100 amps and 240 volts with 3 poles, designed for reliable power distribution control.FDPWS323R features a fusible design suitable for commercial and industrial applications, providing protection and switching capabilities for feeder and branch circuits. It supports a 200kA interrupt rating at 240V AC and is compatible with Class R fuses. The switch has a 3-pole configuration and is built on the FDP frame, accommodating wire sizes from 14 AWG to 1/0 AWG. It is suitable for use in panelboards and switchboards requiring a robust and safe switching solution.

Key Specifications
• Amperage: 100 Amps
• Voltage: 240 VAC, 250 VDC
• Poles: 3
• Interrupt Rating: 200kA at 240 VAC, 10kA at 250 VDC
• Frame/Series: FDP
• Fuse Class: Class R
• Wire Size Range: #14 to 1/0 AWG
• Mounting Type: Panelboard
• HP Rating: 30 HP at 240 VAC, 20 HP at 250 VDC
• Type: Fusible Panelboard Switch

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDPWS323R
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Switch
• Item Subcategory : Panel Mount
• Family : Type FDP
• Type : FDPWS
• Voltage : 240
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 200kA@240V
• Fuse Class : R,H,K
• Configuration : Single
• Switch Style : Fusible
• Nema Rating : 1
• Compatible Frames : TED

Product Data

• UPC : 786679021842
• GTIN : 00786679021842
• Country of Origin : Mexico
• Dimensions : 22.5 in x 10 in x 8 in (Length/Depth x Height x Width)
• Weight : 14.6
• Certification : UL Listed
