FDC3110BP10 - Eaton Series C 110A 3-Pole 600V Molded Case Circuit Breaker

FDC3110BP10

FDC3110BP10 is an Eaton Series C complete molded case circuit breaker designed for three-pole power distribution and motor protection applications. This F-frame breaker delivers reliable fixed thermal and fixed magnetic trip protection with load-side terminals for flexible installation in electrical panels and distribution systems.Technical OverviewThe FDC3110BP10 combines proven Series C performance with robust construction suitable for industrial and commercial environments. Rated at 110 amperes with 600 Vac and 250 Vdc voltage capability, this breaker provides 200 kAIC interrupt rating at 240 Vac and 100 kAIC at 480 Vac. The fixed thermal and magnetic trip mechanism ensures fast response to overload and short-circuit faults while maintaining coordination with upstream and downstream protective devices. Compact dimensions and lightweight design simplify panel layout and installation.

• Amperage Rating: 110 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: Three-pole
• Series: Series C
• Frame Type: F-frame
• Circuit Breaker Type: FDC
• Trip Type: Fixed thermal, fixed magnetic
• Interrupt Rating: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac
• Terminals: Load side
• Frequency Rating: 50/60 Hz
• Certifications: UL Listed
• Product Dimensions: 4.13 in H x 4.13 in W x 3.38 in D
• Product Weight: 4.2 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDC3110BP10
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDC
• Voltage : 600
• Amperage : 110
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 4
