FDC2090LBP10 - Eaton Series C Molded Case Circuit Breaker 90A 600V 2-Pole F-Frame Fixed Thermal Magnetic Trip

FDC2090LBP10

FDC2090LBP10 is a Series C molded case circuit breaker from Eaton, designed for reliable protection in industrial and commercial power distribution systems. This breaker features a fixed thermal and fixed magnetic trip unit, providing dependable overload and short-circuit protection for two-pole applications. The F-frame design ensures compatibility with a wide range of panelboards and switchgear, making it suitable for demanding environments. This Eaton Series C circuit breaker is rated for 90A continuous current and 600 Vac, 250 Vdc, with a high interrupt rating for robust fault protection. The breaker is UL Listed and built to meet rigorous industry standards for safety and performance. Its compact size and load-side terminals facilitate easy installation and maintenance in various electrical enclosures.

• Part Number: FDC2090LBP10
• Manufacturer: Eaton
• Series: Series C
• Frame: F-Frame
• Amperage Rating: 90A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: 2-Pole
• Interrupt Rating: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac
• Mounting Type: Load Side
• Frequency Rating: 50/60 Hz
• Trip Unit: Fixed Thermal, Fixed Magnetic (T186)
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDC2090LBP10
• Manufacturer : Eaton
• Brand : Culter Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDC
• Voltage : 600
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 3
