Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
FDB3070
FDB3070 is a 70 amp, 600V, 3-pole molded case circuit breaker from Eaton, designed for reliable protection in industrial and commercial applications.
This Eaton Series C, F-frame circuit breaker features a fixed thermal magnetic trip unit, panel mounting, and a high interrupting capacity. It is suitable for three-phase systems, offers standard pressure line and load terminals, and is certified for safety and performance.
-
Key Specifications
- Part Number: FDB3070
- Manufacturer: Eaton
- Amperage: 70A
- Voltage: 600V AC, 250V DC
- Poles: 3
- Mounting Type: Panel mount
- Interrupt Rating: 14kA @ 480V, 18kA @ 240V
- Series/Frame: Series C, F-frame (FDB)
- Trip Unit: Fixed thermal magnetic (LI – Long-Time and Instantaneous)
- Certifications: UL, CSA, CE
- Connection: Feed-thru
- Dimensions: 6" H x 4.13" W x 3.38" D
- Weight: 4.5 lbs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FDB3070
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FDB
- Voltage : 600
- Amperage : 70
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 786679305973
- GTIN : 00786679305973
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
