FDB3030L - Cutler Hammer 30 Amp 600V 3-Pole Series C Molded Case Circuit Breaker

FDB3030L

FDB3030L is a Cutler Hammer Series C molded case circuit breaker rated for 30 amps and 600 volts with three poles.This circuit breaker features a thermal magnetic trip unit (T186), a 14kA interrupt rating at 480VAC, and is designed for panelboard, switchboard, motor control center, and busway applications. It is UL listed and CSA certified, providing reliable protection and compliance with industry standards.

• Amperage: 30 Amp
• Voltage Rating: 600 VAC / 250 VDC
• Poles: 3
• Series/Frame: Series C, F-Frame
• Trip Type: Thermal Magnetic (T186)
• Interrupt Rating: 14kA at 480VAC, 18kA at 240VAC
• Mounting Type: Panel Mount
• Certifications: UL Listed, CSA Certified
• Application: Panelboard, Switchboard, Motor Control Center, Busway
• Wire Range: 14 to 1/0 AWG

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB3030L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679305881
• GTIN : 00786679305881
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
