FDB3015L - Cutler Hammer 15 Amp 600V 3 Pole Molded Case Circuit Breaker F Frame Thermal Magnetic

FDB3015L

FDB3015L is a Cutler Hammer 15 amp, 3 pole molded case circuit breaker designed for 600V applications with thermal magnetic trip protection.This F Frame Series C breaker features a feed-thru mounting type and offers a standard interrupting rating of 14kA at 480V. It includes long-time and instantaneous (LI) trip functions with line and load side lug terminals. The breaker is UL and CSA certified, suitable for panel mounting, and rated for 250 VDC as well.

Key Specifications
• Amperage: 15 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Mounting Type: Feed-Thru
• Interrupt Rating: 14kA @ 480 VAC, 18kA @ 240 VAC
• Series/Frame: Series C, F Frame (FDB)
• Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous) trip
• Certifications: UL, CSA
• Dimensions: 6" H x 4.13" W x 3.38" D
• Weight: Approx. 4.5 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB3015L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679305836
• GTIN : 00786679305836
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
