FDB2080L - Eaton 80A 600V 2-Pole Series C Molded Case Circuit Breaker F-Frame Fixed Thermal Magnetic Trip

FDB2080L

FDB2080L is an Eaton Series C molded case circuit breaker designed for reliable circuit protection in electrical systems.

This 2-pole breaker features an 80 ampere rating and is rated for 600 volts AC and 250 volts DC operation. It has a fixed thermal, fixed magnetic trip unit and is part of Eaton's F-frame Series C line. The breaker offers an interrupt rating of 18 kAIC at 240 VAC and 14 kAIC at 480 VAC, suitable for various industrial and commercial applications. It supports line and load connections and operates at 50/60 Hz frequency.

Key Specifications
• Amperage: 80 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 2
• Interrupt Rating: 18 kAIC at 240 VAC, 14 kAIC at 480 VAC
• Series/Frame: Series C, F-Frame
• Trip Type: Fixed thermal, fixed magnetic
• Frequency: 50/60 Hz
• Connection Type: Line and load

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB2080L
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 80
• Phase : 1
• Poles : 2
• AIC rating : 14kA@600V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679325100
• GTIN : 00786679325100
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 3.5 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
