FDB2045BP10 - Eaton Series C 45 Amp 600V 2-Pole Molded Case Circuit Breaker

FDB2045BP10

FDB2045BP10 is an Eaton Series C molded case circuit breaker designed for reliable thermal-magnetic protection in industrial and commercial electrical systems.

This F-frame, two-pole breaker features a 45-ampere rating at 600 VAC (250 VDC) with fixed thermal and fixed magnetic trip characteristics. The FDB type construction delivers high-speed blow-open contact action for superior arc suppression and performance. With an interrupt rating of 18 kAIC at 240 VAC and 14 kAIC at 480 VAC, this breaker provides dependable overcurrent and short-circuit protection. Line and load side terminals accommodate standard wire connections for flexible installation.

• Amperage Rating: 45 A
• Voltage Rating: 600 VAC, 250 VDC
• Number of Poles: Two-Pole
• Frame Type: F-Frame
• Series: Series C
• Trip Type: Fixed Thermal, Fixed Magnetic
• Interrupt Rating: 18 kAIC at 240 VAC, 14 kAIC at 480 VAC
• Frequency Rating: 50/60 Hz
• Certifications: UL Listed
• Terminal Configuration: Line and Load Side

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FDB2045BP10
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FDB
• Voltage : 600
• Amperage : 45
• Phase : 1
• Poles : 2
• AIC rating : 14kA@600V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• Weight : 3
