FD4040 - Eaton 4-Pole 40A 600VAC Molded Case Circuit Breaker

FD4040

FD4040 is a Series C molded case circuit breaker from Eaton designed for industrial and commercial power distribution applications.

The FD4040 features a 4-pole configuration with a 40-ampere rating and supports dual voltage operation at 600 VAC and 250 VDC. This Type FD breaker incorporates fixed thermal and fixed magnetic trip protection with a T186 trip unit for reliable overcurrent and short-circuit protection. The F-frame design provides compact mounting in standard electrical panels with dimensions of 6 inches in height, 3.38 inches in length, and 5.5 inches in width. The unit weighs approximately 2 kg and is manufactured in the United States.

• Amperage Rating: 40 A
• Poles: 4
• Voltage Rating: 600 VAC, 250 VDC
• Circuit Breaker Type: FD
• Series: C
• Frame Size: F-frame
• Trip Unit: T186 (Fixed Thermal/Fixed Magnetic)
• Interrupt Rating: 65 kA @ 240 VAC, 35 kA @ 480 VAC, 18 kA @ 600 VAC
• Mounting: Panel
• Height: 6 inches (15.24 cm)
• Weight: 2.025 kg

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD4040
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 40
• Phase : 3
• Poles : 4
• AIC rating : 25kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 078667925075
• GTIN : 00786679250754
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
