FD3090 - Cutler Hammer Series C 3 Pole 90A 600V Molded Case Circuit Breaker

FD3090

FD3090 is a Cutler Hammer Series C 3 pole, 90A, 600V molded case circuit breaker designed for reliable thermal magnetic protection in commercial and industrial applications. This breaker features F-frame construction, feed-thru connections, and a 35kA interrupt rating at 480V, making it suitable for a wide range of power distribution needs. The unit includes LI (Long-Time and Instantaneous) trip functions and is rated for 40°C ambient temperature.

• Part Number: FD3090
• Manufacturer: Cutler Hammer
• Series/Frame: Series C, F-Frame
• Poles: 3
• Amperage: 90A
• Voltage: 600V AC, 250V DC
• Interrupt Rating: 35kA @ 480V
• Mounting Type: Feed-Thru
• Protection Type: Thermal Magnetic
• Phase: 3-Phase
• Temperature Rating: 40°C
• Standards: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3090
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Load Side Lug
• Frame Size : 225A/F
• Temp Rating : Minimum Operating Temp -4 Degrees F Max. Operating Temp.158 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 1/0 AWG
• Breaker Type : Standard
• Protection : Thermal Magnetic
• Phase Connection : ABC

Product Data

• UPC : 786679305751
• GTIN : 00786679305751
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Panel Type : Allen Bradley MCC, Eaton MCC Eaton, Rockwell Automation Enclosed Control, Switchboard, Westinghouse
• Standards : CSA Certified, IEC Rated, UL Listed
• Certification : CSA Certified, IEC Rated, UL Listed
