FD3015L - Cutler Hammer 3 Pole 15A 600V Molded Case Circuit Breaker, FD Frame, Series C, Thermal Magnetic Trip, UL Listed

FD3015L

FD3015L is a Cutler Hammer (Eaton) molded case circuit breaker designed for reliable protection in commercial and industrial applications.

This 3-pole breaker features a 15A amperage rating, 600V AC voltage rating, and is part of the Series C, FD frame family. It utilizes a thermal magnetic, non-interchangeable trip unit for consistent performance and is UL Listed for safety compliance. The breaker offers a standard interrupting capacity of 35kA at 480V AC and is rated for feed-thru applications.

Key Specifications
• Part Number: FD3015L
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 15A
• Voltage: 600V AC, 250V DC
• Poles: 3
• Mounting Type: Molded case, bolt-on
• Interrupt Rating: 35kA @ 480V AC, 65kA @ 240V AC, 18kA @ 600V AC
• Series/Frame: Series C, FD frame
• Trip Unit: Thermal magnetic, non-interchangeable
• Certifications: UL Listed
• Operating Temperature: Rated for 40°C
• Application: Feed-thru design

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD3015L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679305614
• GTIN : 00786679305614
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.45
• Certification : UL Listed
