FD1125 - Eaton FD Series 125A 347VAC 1-Pole Molded Case Circuit Breaker

FD1125

FD1125 is a single-pole molded case circuit breaker from Eaton's FD Series, designed for reliable protection in commercial and industrial applications. This breaker features a fixed thermal and fixed magnetic trip unit, providing dependable overcurrent protection for circuits up to 125A and 347VAC. It is built for F-frame mounting and is suitable for use in a wide range of electrical distribution systems.Engineered for durability and safety, the FD1125 offers a robust design with a high-speed blow-open contact mechanism for superior performance. It is compatible with a broad range of Eaton accessories and is UL Listed for safety compliance. The breaker is rated for 35 kAIC at 277VAC and 18 kAIC at 347VAC, making it suitable for demanding environments.

• Part Number: FD1125
• Manufacturer: Eaton
• Series: FD Series
• Frame Type: F-frame
• Amperage: 125A
• Voltage Rating: 347VAC, 125VDC
• Poles: 1
• Interrupt Rating: 35 kAIC at 277VAC, 18 kAIC at 347VAC
• Mounting Type: F-frame
• Frequency Rating: 50/60 Hz
• Trip Unit: Fixed Thermal/Fixed Magnetic
• UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FD1125
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : FD
• Voltage : 277
• Amperage : 125
• Phase : 1
• Poles : 1
• AIC rating : 35kA@277V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679312605
• GTIN : 00786679312605
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 0.001
• Certification : UL Listed,UL 489
