Product Info
- Manufacturer:Westinghouse
- Sub-Category:Molded Case
Description
FD1045
FD1045 is a 1 pole, 45 amp, 277 volt bolt-on circuit breaker designed for reliable protection in commercial and industrial applications. This Westinghouse FD1045 breaker features a thermal magnetic trip unit, 35kA interrupting capacity at 277V, and is part of the FD frame series. It is engineered for bolt-on mounting and provides dependable circuit protection for lighting and power distribution systems.
- Part Number: FD1045
- Manufacturer: Westinghouse
- Amperage: 45A
- Voltage: 277V AC
- Poles: 1
- Mounting Type: Bolt-On
- Interrupt Rating: 35kA@277V
- Series/Frame: FD
- Protection Type: Thermal Magnetic
- Application: Commercial, Industrial
- Load Terminals: Load Only
- Standards: UL Listed
Specifications
- Part Number: FD1045
- Manufacturer : Westinghouse
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : FD
- Voltage : 277
- Amperage : 45
- Phase : 1
- Poles : 1
- AIC rating : 35kA@277V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Frame Size : F Frame
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679312575
- GTIN : 00786679312575
- Country of Origin : Dominican Republic
- Dimensions : 3.38 in x 6 in x 1.38 in (Length/Depth x Height x Width)
- Weight : 4.5
- Certification : UL Listed
