Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FCP34100TF
FCP34100TF is a 3 pole molded case circuit breaker from Square D designed for 480 volt applications with a 100 amp current rating. This feed-through style breaker delivers reliable thermal magnetic protection for industrial and commercial power distribution systems.Technical Overview
The FCP34100TF features an I-Line style plug-in connection and includes long-time and instantaneous trip functions for comprehensive circuit protection. With an interrupting rating of 65kAIC at 480V, this breaker is rated for UL and CSA approval, ensuring compliance with North American electrical standards. The unit weighs 2.96 lbs and is engineered for dependable performance in demanding electrical environments.
- Amperage: 100 Amps
- Voltage: 480VAC
- Poles: 3
- Phase: 3 Phase
- Series: FCP
- Interrupting Rating: 65kAIC at 480V
- Connection Type: I-Line Style Plug-In
- Trip Functions: Long-Time and Instantaneous
- Protection Type: Thermal Magnetic
- Certifications: UL, CSA
- Weight: 2.96 lbs
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FCP34100TF
- Manufacturer : Square D
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FCP Series
- Type : FCP
- Voltage : 480
- Amperage : 100
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 7
