Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
FAL340601590
FAL340601590 is a 60 amp, 3-pole, 480 Volt thermal magnetic circuit breaker from Square D's FAL Series.This circuit breaker is designed for reliable protection of electrical circuits with a thermal magnetic trip unit. It features a 3-pole configuration suitable for three-phase applications and is rated for 480 volts. The breaker provides a robust interrupting capacity suitable for commercial and industrial use.
- Amperage: 60 Amps
- Voltage Rating: 480 Volts
- Poles: 3
- Series: FAL
- Trip Unit: Thermal Magnetic
- Mounting Type: Individually Mounted
- Interrupt Rating: 18 kAIC at 480V
- UL Listed and CSA Certified
Specifications
- Part Number: FAL340601590
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAL Series
- Type : FAL
- Voltage : 480
- Amperage : 60
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 5
