Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
FAL34060
FAL34060 is a Square D FAL Series 3-pole molded case circuit breaker designed for reliable protection in commercial and industrial applications.
This thermal magnetic circuit breaker features a 60A amperage rating, 480V voltage rating, and 3-pole configuration. It offers bolt-on mounting, feed-thru lug connections, and an interrupting rating of 18kAIC at 480V. The FAL34060 is UL, CSA, and CE listed for safety and compliance.
-
Key Specifications
- Part Number: FAL34060
- Manufacturer: Square D
- Series/Frame: FAL
- Amperage: 60A
- Voltage: 480VAC
- Poles: 3
- Phase: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 18kAIC at 480V
- Trip Unit: Thermal Magnetic (LI – Long-Time and Instantaneous)
- Connection Type: Feed-Thru Lugs
- Certifications: UL, CSA, CE
- Terminal Wire Size: 14 to 4 AWG
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.
Specifications
- Part Number: FAL34060
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : FAL Series
- Type : FAL
- Voltage : 480
- Amperage : 60
- Phase : 3
- Poles : 3
- AIC rating : 18kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous Trip
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- UPC : 785901423386
- GTIN : 00785901423386
- Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
- Weight : 5.031
- Certification : UL, CSA
