FAB36070 - Square D I-Line Bolt-On 600V 70A 3 Pole Molded Case Circuit Breaker

FAB36070

FAB36070 is a 3 pole, 600 Volt, 70 amp rated molded case circuit breaker designed for I-Line power distribution systems. This Square D breaker features a bolt-on mounting style and is built for reliable circuit protection in commercial and industrial applications. Engineered with a 100 amp frame and thermal magnetic trip unit, the FAB36070 offers an interrupt rating of 25kA at 480V. It is part of the Square D I-Line series and is suitable for use in panelboards requiring bolt-on installation. The breaker includes lock-down screws for vibration-proof fastening and is certified for safety and performance.

• Part Number: FAB36070
• Manufacturer: Square D
• Amperage: 70A
• Voltage: 600V
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 25kA @ 480V
• Series/Frame: I-Line, 100A Frame
• Trip Unit: Thermal Magnetic
• Application: Molded Case Circuit Breaker
• Features: Lock-Down Screws
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAB36070
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FAB
• Voltage : 600
• Amperage : 70
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : I-Line Style Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• GTIN : 00785901241294
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 6.55
