FAB34020 - Square D 20A 480V 3 Pole I-Line Style Circuit Breaker FA Frame

FAB34020

FAB34020 is a 3 pole, 20 amp, 480 Volt circuit breaker from Square D designed for I-Line style bolt-on mounting.This thermal magnetic molded case circuit breaker features a 18kA interrupting rating at 480VAC, long-time and instantaneous trip functions, and is UL and CSA certified. It is part of the FA series/frame with a 275A magnetic hold current and 600A magnetic trip current, suitable for power distribution applications.

• Manufacturer: Square D
• Part Number: FAB34020
• Amperage: 20 Amps
• Voltage Rating: 480 VAC
• Poles: 3
• Mounting Type: I-Line Style Bolt-On
• Interrupting Rating: 18kA at 480V
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Trip
• Frame/Series: FA
• Certifications: UL, CSA
• Terminal Connection: Load Side Lug
• Dimensions: Approx. 4.5" W x 4.13" D x 6.4" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: FAB34020
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : I-Line
• Type : FAB
• Voltage : 480
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : I-Line Style Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 785901403885
• GTIN : 00785901128687
• Country of Origin : Mexico
• Dimensions : 6.4 in (162.6 mm) x 4.5 in (114.3 mm) x 4.13 in (104.90 mm) (Height x Width x Depth)
• Weight : 9
