EJB36080 - Square D E-Frame 80A 3-Pole 600Y/347VAC Miniature Circuit Breaker, Thermal Magnetic Trip, Bolt-On Mount

EJB36080

EJB36080 is a Square D E-Frame miniature circuit breaker designed for reliable branch circuit protection in commercial and industrial applications. This 3-pole breaker features a thermal-magnetic trip unit and bolt-on mounting for secure installation. The EJB36080 is rated for 80A at 600Y/347VAC and is suitable for use in panelboards requiring high interrupt capacity. Its compact design and robust construction make it ideal for demanding electrical environments.

• Part Number: EJB36080
• Manufacturer: Square D
• Series/Frame: E-Frame
• Amperage Rating: 80A
• Voltage Rating: 600Y/347VAC
• Number of Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 100 kA at 240 VAC / 65 kA at 480Y/277 VAC
• Tripping Mechanism: Thermal-Magnetic
• Wire Size: AWG 12 to AWG 2/0
• UL Listed (US and Canada)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB36080
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 600
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78590125677
• GTIN : 00785901256779
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.45
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
