EJB36050 - Square D 600V 50A 3 Pole Bolt-On Molded Case Circuit Breaker

EJB36050

EJB36050 is a 3 pole, 600 Volt, 50 amp rated molded case circuit breaker designed for reliable protection in commercial and industrial applications. Manufactured by Square D, this breaker features a bolt-on mounting style and is suitable for use in panelboards requiring high interrupt capacity and dependable thermal-magnetic tripping. This EJB36050 circuit breaker is part of the EJB series and is calibrated for 40 degrees C. It features aluminum lugs with a terminal lug rating of AWG 12 to AWG 6 (aluminum) and AWG 14 to AWG 6 (copper). The breaker is rated for 65kA AIC at 480V and 25kA at 600V, ensuring robust protection in demanding environments. The tripping mechanism is thermal-magnetic, and the unit meets cULus certification standards.

• Part Number: EJB36050
• Manufacturer: Square D
• Series/Frame: EJB
• Amperage: 50A
• Voltage: 600Y/347V
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA@480V, 25kA@600V
• Tripping Mechanism: Thermal-Magnetic
• Terminal Lug Rating: AWG 12-6 (Aluminum), AWG 14-6 (Copper)
• Calibration: 40°C
• Certifications: cULus

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB36050
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901407133
• GTIN : 00785901407133
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.45
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
