EJB36045 - Square D 45A 3-Pole 600Y/347V Molded Case Circuit Breaker

EJB36045

EJB36045 is a Square D molded case circuit breaker designed for branch circuit protection in Class 515 NF series panelboards.

This thermal-magnetic circuit breaker features bolt-on mounting and is rated for 45 amperes at 600Y/347 volts AC. The breaker provides reliable protection with a trip unit rating of 875 amperes and interrupt ratings of 100 kA at 240 VAC and 65 kA at 480Y/277 VAC. It is suitable for lighting applications and carries UL and CSA approvals for use in both the United States and Canada.

Key Specifications

• Part Number: EJB36045
• Manufacturer: Square D
• Amperage Rating: 45 Amp
• Number of Poles: 3
• Voltage Rating: 600Y/347 VAC
• Mounting Type: Bolt-On
• Trip Unit Rating: 875 Amp
• Interrupt Rating: 100 kA at 240 VAC / 65 kA at 480Y/277 VAC
• Tripping Mechanism: Thermal-Magnetic
• Certifications: UL, CSA
• Wire Size: 12-2/0 AWG (Aluminum) / 14-2/0 AWG (Copper)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EJB36045
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EJB Series
• Type : EJB
• Voltage : 600
• Amperage : 45
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 104 °F (40 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078590140704
• GTIN : 00785901407041
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 2.94 in (74.68 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 3.45
• Panel Type : NF panelboard
• Certification : cULus
• Wire Size : AWG 12...AWG 2/0 aluminum
  AWG 14...AWG 2/0 copper
