Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3090W
EHD3090W is a 90 amp, 480 volt, 3-pole molded case circuit breaker from Eaton's Series C, F-frame EHD line. The EHD3090W features fixed thermal and magnetic trip units designed for reliable protection in industrial and commercial electrical systems. It operates at 50/60 Hz frequency and is rated for a 14 kA interrupting capacity at 480 VAC. This complete breaker includes load-side terminals and is designed for fixed mounting.
- Manufacturer: Eaton
- Part Number: EHD3090W
- Amperage: 90A
- Voltage Rating: 480 VAC, 250 VDC
- Poles: 3
- Series/Frame: Series C, F-frame
- Trip Unit: Fixed thermal and magnetic
- Interrupt Rating: 14 kA at 480 VAC
- Frequency: 50/60 Hz
- Mounting Type: Fixed
- Terminals: Load side
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
Specifications
- Part Number: EHD3090W
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 90
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
