EHD3080W - Eaton 80 Amp 3-Pole 480V Molded Case Circuit Breaker C Series

EHD3080W

EHD3080W is an 80 Amp, 3-pole molded case circuit breaker from Eaton's C Series designed for reliable circuit protection in industrial and commercial applications. This breaker supports a maximum voltage of 480 VAC and features a thermal magnetic trip unit for precise overload and short circuit protection. It is UL Listed, ensuring compliance with safety standards.EHD3080W offers a compact design with dimensions approximately 4.13 inches wide, 3.38 inches deep, and 6 inches high. It has an interrupt rating of 18 kAIC at 240 VAC and 14 kAIC at 480 VAC, suitable for demanding electrical environments. The breaker is designed for panel or enclosure mounting and provides dependable performance in a variety of power distribution systems.

Key Specifications
• Amperage: 80 Amp
• Poles: 3
• Maximum Voltage: 480 VAC
• Series/Frame: C Series
• Trip Unit: Thermal Magnetic (T186)
• Interrupt Rating: 18 kAIC at 240 VAC, 14 kAIC at 480 VAC
• Certifications: UL Listed
• Dimensions: 4.13 in W x 3.38 in D x 6 in H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: EHD3080W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 80
• Phase : 3
• Poles : 3
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679094075
• GTIN : 00786679094075
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 4.5
• Certification : UL Listed
