- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
EHD3070YBP10
EHD3070YBP10 is an Eaton Series C molded case circuit breaker designed for reliable power distribution and circuit protection in industrial and commercial applications. This three-pole, 70-ampere F-frame breaker features fixed thermal-magnetic trip protection and is rated for 480V AC and 250V DC operation at 50/60 Hz. The load-side terminal configuration provides flexible installation options for panel mounting and bus bar connections. Key Specifications
- Amperage Rating: 70A
- Poles: 3-Pole
- Frame Size: F-Frame
- Voltage Rating: 480V AC / 250V DC
- Trip Type: T186 Fixed Thermal-Magnetic
- Interrupt Rating: 18kA @ 240VAC, 14kA @ 480VAC
- Frequency: 50/60 Hz
- Series: Eaton Series C EHD Type
- Terminal Configuration: Load-Side Busbar
- Certification: UL Listed
Specifications
- Part Number: EHD3070YBP10
- Manufacturer : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : EHD
- Voltage : 480
- Amperage : 70
- Phase : 3
- Poles : 3
- AIC rating : 14kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : F Frame
- Protection : Thermal Magnetic
Product Data
- Weight : 4
