EHD2090 - Cutler Hammer 90 Amp 480 Volt 2 Pole Molded Case Circuit Breaker Series C Frame

EHD2090

EHD2090 is a Cutler Hammer 2 Pole molded case circuit breaker rated for 90 Amps and 480 Volts, designed for reliable thermal magnetic protection.This Series C Frame breaker features a fixed thermal and magnetic trip unit with a 14kA interrupt rating at 480VAC and 18kA at 240VAC. It is suitable for panel and electrical assembly applications requiring robust circuit protection.

• Amperage: 90 Amp
• Voltage: 480 VAC
• Poles: 2
• Frame: Series C, F Frame
• Trip Unit: Fixed Thermal Magnetic
• Interrupt Rating: 14kA @ 480VAC, 18kA @ 240VAC
• Mounting Type: Molded Case
• Frequency: 50/60 Hz
• Feed-Thru Capability: Yes
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2090
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679317501
• GTIN : 00786679317501
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
