EHD2050L - Cutler Hammer 50 Amp 480V 2-Pole F-Frame Molded Case Circuit Breaker Thermal Magnetic

EHD2050L

EHD2050L is a Cutler Hammer 2-pole molded case circuit breaker with a 50 ampere rating and 480 VAC voltage capacity designed for panel mounting.This F-frame breaker features a fixed thermal and fixed magnetic trip unit, providing reliable protection with an interrupting rating of 14 kA at 480 VAC and 18 kA at 240 VAC. It is part of the Eaton Series C family, suitable for 50/60 Hz applications, and meets UL 489 certification standards.

• Amperage: 50 A
• Voltage: 480 VAC, 250 VDC
• Poles: 2
• Frame: F-Frame (Series C)
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 14 kA at 480 VAC, 18 kA at 240 VAC
• Mounting Type: Panel Mount
• Frequency: 50/60 Hz
• UL Certified: UL 489
• Weight: Approx. 3.1 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EHD2050L
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EHD
• Voltage : 480
• Amperage : 50
• Phase : 1
• Poles : 2
• AIC rating : 14kA@480V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous Trip
• Frame Size : F Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679850893
• GTIN : 00786679850893
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 2.75 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
