Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGH2040FFG
EGH2040FFG is a Cutler Hammer 2 pole thermal magnetic molded case circuit breaker rated for 40 amps and 600 volts, designed for reliable power distribution protection.This circuit breaker belongs to the EG frame Series G family and features a high interrupting capacity of 65kA at 480V. It supports feed-thru mounting with line and load side lug terminals, providing long time and instantaneous trip functions with a non-interchangeable trip unit.
- Key Specifications
- Manufacturer: Cutler Hammer (Eaton)
- Amperage: 40 Amps
- Voltage Rating: 600Y/347 VAC
- Number of Poles: 2
- Frame Type: EG Frame, Series G
- Interrupt Rating: 65kA at 480V
- Trip Unit: Thermal Magnetic, Non-Interchangeable
- Mounting Type: Feed-Thru with collars and mounting hardware
- Phase: Single Phase
- Line & Load Side Lug Terminals
- Certifications: UL Listed (implied by manufacturer standard)
- Part Number: EGH2040FFG
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGH
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Feed-Thru
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
- UPC : 786685019017
- GTIN : 00786685019017
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
- Weight : 2
- Certification : UL Listed,CSA Certified,IEC Rated,CE Marked
