Product Info
- Manufacturer:Cutler Hammer
- Sub-Category:Molded Case
Description
EGH2040FFB
EGH2040FFB is a Cutler Hammer Series G molded case circuit breaker with a 40 amp rating and 2 poles designed for bolt-on mounting.This circuit breaker features a fixed thermal and fixed magnetic trip unit, suitable for 600Y/347 VAC applications with a high interrupt rating of 65 kAIC at 480 VAC. It belongs to the EG frame series and is UL listed, CSA certified, IEC rated, and CE marked for safety and compliance.
- Key Specifications
- Amperage: 40A
- Voltage: 600Y/347 VAC
- Poles: 2
- Mounting Type: Bolt-On
- Interrupt Rating: 65 kAIC at 480 VAC, 100 kAIC at 240 VAC, 35 kAIC at 600Y/347 VAC
- Series/Frame: EG Frame, Series G
- Trip Unit: Fixed Thermal, Fixed Magnetic
- Frequency: 50/60 Hz
- Certifications: UL Listed, CSA Certified, IEC Rated, CE Marked
- Weight: 1.83 lb
- Part Number: EGH2040FFB
- Manufacturer : Cutler Hammer
- Brand : Cutler Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series G
- Type : EGH
- Voltage : 600
- Amperage : 40
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LI - Long Time and Instantaneous
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
- UPC : 786685232799
- GTIN : 00786685232799
- Country of Origin : Dominican Republic
- Dimensions : 2.99 in x 5.5 in x 2 in (Length/Depth x Height x Width)
- Weight : 1.83
- Certification : UL Listed,CSA Certified,IEC Rated,CE Marked
