EDS2175 - Westinghouse 240V 175A 2 Pole Molded Case Circuit Breaker Series C F-Frame

EDS2175

EDS2175 is a 2 pole, 240V, 175A molded case circuit breaker from the Series C F-Frame family, designed for reliable circuit protection in commercial and industrial applications. Manufactured by Westinghouse, this breaker features a fixed thermal magnetic trip unit and is UL Listed for safety and performance. It is suitable for use in panelboards and switchgear requiring robust protection and easy installation. This breaker is part of the Series C F-Frame line, known for durability and compatibility with a wide range of electrical systems. The EDS2175 is rated for 240V AC and 125V DC, with an interrupting capacity of 42kA at 240V. It is HACR rated and suitable for use in HVAC, lighting, and motor circuits. The bolt-on mounting design ensures secure installation and easy replacement.

• Part Number: EDS2175
• Manufacturer: Westinghouse
• Amperage Rating: 175A
• Voltage Rating: 240V AC, 125V DC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 42kA @ 240V
• Series/Frame: Series C F-Frame
• Tripping Unit: Fixed Thermal Magnetic
• Certifications: UL Listed, HACR Rated
• Application: Commercial, Industrial
• Compatible With: Panelboards, Switchgear

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDS2175
• Manufacturer : Westinghouse
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : EDS
• Voltage : 240
• Amperage : 175
• Phase : 2
• Poles : 2
• AIC rating : 42kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous
• Frame Size : F Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 782116152636
• GTIN : 00782116152636
• Country of Origin : Dominican Republic
• Dimensions : 3.38 in x 6 in x 4.13 in (Length/Depth x Height x Width)
• Weight : 3
• Certification : UL Listed
