EDB34125AABASA - Schneider Electric E-Frame 125A 3-Pole 480Y/277VAC 25kA Max Bolt-On Circuit Breaker with Shunt Trip, Alarm, and Aux Switch

SKU: EDB34125AABASA-New
Condition: New
Price:
$4,814.87
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

EDB34125AABASA - Square D Bolt-On 480V 125A 3 pole circuit breaker 18kA@480V - Essential Electric Supply
EDB34125AABASA - Square D Bolt-On 480V 125A 3 pole circuit breaker 18kA@480V - Essential Electric Supply
EDB34125AABASA - Schneider Electric E-Frame 125A 3-Pole 480Y/277VAC 25kA Max Bolt-On Circuit Breaker with Shunt Trip, Alarm, and Aux Switch - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
EDB34125AABASA - Square D Bolt-On 480V 125A 3 pole circuit breaker 18kA@480V - Essential Electric Supply
EDB34125AABASA - Square D Bolt-On 480V 125A 3 pole circuit breaker 18kA@480V - Essential Electric Supply
EDB34125AABASA - Schneider Electric E-Frame 125A 3-Pole 480Y/277VAC 25kA Max Bolt-On Circuit Breaker with Shunt Trip, Alarm, and Aux Switch - Essential Electric Supply

Description

EDB34125AABASA


EDB34125AABASA is a 3-pole, 125A, 480Y/277VAC molded case circuit breaker from Schneider Electric's E-Frame series, designed for reliable protection in commercial and industrial applications. This breaker features bolt-on mounting, a shunt trip, alarm switch, and auxiliary switch for enhanced control and monitoring. The EDB34125AABASA provides superior overload and short circuit protection with a maximum interrupt rating of 25kA at 240VAC and 18kA at 480Y/277VAC. It is compatible with a wide range of wire sizes and is ideal for use in lighting panelboards and other demanding environments. The breaker includes Visi-Trip™ technology for easier troubleshooting and is UL listed, CSA certified, and HOM certified for safety and compliance.
  • 125A rated current
  • 3-pole configuration
  • 480Y/277VAC maximum operating voltage
  • Bolt-on mounting
  • 25kA interrupt rating at 240VAC
  • 18kA interrupt rating at 480Y/277VAC
  • E-Frame series
  • Thermal magnetic trip unit
  • Shunt trip, alarm switch, and auxiliary switch included
  • UL listed
  • CSA certified
  • HOM certified
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

complete with auxiliary switch/alarm switch/shunt trip package


Specifications

  • Part Number: EDB34125AABASA
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : EDB Series
  • Type : EDB
  • Voltage : 480
  • Amperage : 125
  • Phase : 3
  • Poles : 3
  • AIC rating : 18kA@480V
  • Connection : Bolt-On
  • Functions : LI - Long-Time and Instantaneous
  • Terminal Connection : Lug
  • Temp Rating : 104 ¡F (40 ¡C)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901950202
  • GTIN : 00785901950202
  • Country of Origin : Mexico
  • Dimensions : 5.66 in (143.76 mm) x 3.92 in (99.57 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
  • Weight : 4.178
  • Panel Type : NF panelboard
  • Standards : cULus, IEC
  • Certification : cULus, IEC
  • Wire Size : AWG 12...AWG 2/0 aluminum
    AWG 14...AWG 2/0 copper
