EDB34030AABA - Schneider Electric 30A 3-Pole 480Y/277V Bolt-On Molded Case Circuit Breaker E-Frame

EDB34030AABA

EDB34030AABA is a Schneider Electric E-Frame molded case circuit breaker rated at 30A, 3-pole, 480Y/277V AC with bolt-on mounting.

This thermal-magnetic miniature circuit breaker from the EDB series provides overload and short-circuit protection for NF panelboards. It features a trip unit rating of 875A, holding current of 270A, and Visi-Trip indicator for local trip signaling. The breaker supports aluminum and copper wire connections with AWG 14-6 copper or AWG 12-6 aluminum lugs and is HACR-rated and HID-rated.

Key Specifications

• Amperage: 30A
• Voltage: 480Y/277V AC
• Poles: 3
• Mounting Type: Bolt-on
• Series/Frame: E-Frame
• Trip Unit: Thermal-magnetic
• Interrupt Rating: 18kA at 480Y/277V AC; 25kA at 240V AC
• Line Rated Current: 30A
• Trip Unit Rating: 875A
• Holding Current: 270A
• Certifications: UL listed; CSA
• Wire Range: AWG 14-6 copper; AWG 12-6 aluminum

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: EDB34030AABA
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : EDB Series
• Type : EDB
• Voltage : 480
• Amperage : 30
• Phase : 3
• Poles : 3
• AIC rating : 18kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Lug
• Temp Rating : 104 ¡F (40 ¡C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901532187
• GTIN : 00785902000000
• Country of Origin : Mexico
• Dimensions : 5.66 in (143.76 mm) x 3.92 in (99.57 mm) x 4.05 in (102.87 mm) (Height x Width x Depth)
• Weight : 4.244
• Standards : cULus, IEC
• Certification : cULus, IEC
