ED63A001L - Siemens 1A 600V 3 Pole Molded Case Circuit Breaker Bolt-On

ED63A001L

ED63A001L is a Siemens Sentron Series molded case circuit breaker designed for low-voltage industrial and commercial electrical systems.

This 3-pole breaker features a bolt-on connection type and provides reliable overload and short-circuit protection. The breaker is rated for 600 VAC at 50/60 Hz and 250 VDC operation. It is equipped with electronic or thermal-magnetic trip protection with adjustable trip settings, making it suitable for precise coordination in distribution boards, MCC/PCC systems, industrial machines, HVAC systems, and commercial installations. The breaker protects against overloads, short circuits, and earth faults when equipped, with adjustable settings for system safety and downstream device coordination.

• Part Number: ED63A001L
• Manufacturer: Siemens / ITE
• Series: Sentron ED Type
• Poles: 3
• Amperage: 1 Amp
• Voltage: 600 VAC / 250 VDC
• Frequency: 50/60 Hz
• Connection Type: Bolt-On
• Breaking Capacity: 25 kA
• Trip Unit: Electronic with adjustable settings (2.6 to 9 Ampere range)
• Protection: Overload and Short Circuit

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ED63A001L
• Manufacturer : Siemens
• Brand : Siemens
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Sentron Series
• Type : ED
• Voltage : 600 AC
• Amperage : 1
• Phase : 3
• Poles : 3
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : I - Instantaneous
• Frame Size : ED Frame
• Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
• Protection : Magnetic Only

Product Data

• Country of Origin : Mexico
• Dimensions : 6.693 x 5.906 x 3.952
• Weight : 8
• Certification : Ul Listed, IEC
