Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
ED41B025L
ED41B025L is a Siemens molded case circuit breaker with a 25 amp rating, designed for 1-pole, 120 volt applications in the ED frame series.ED41B025L features a standard 40¡C thermal trip unit with a non-interchangeable trip mechanism. It meets UL 489 and IEC 60947-2 standards and offers a 65kA interrupt rating at 120V, ensuring reliable circuit protection. The breaker includes line and load lugs for easy installation.
- Amperage: 25 Amp
- Voltage: 120 Volt
- Poles: 1
- Frame/Series: ED Frame
- Interrupt Rating: 65kA at 120V
- Trip Unit: Thermal, Non-Interchangeable
- Mounting Type: Standard molded case
- Standards: UL 489, IEC 60947-2
- Operating Temperature: 40¡C standard
- Connection Type: Line and Load Lugs Installed
Specifications
- Part Number: ED41B025L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : ED
- Voltage : 120 AC
- Amperage : 25
- Phase : 1
- Poles : 1
- AIC rating : 65kA@120V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : ED Frame
- Temp Rating : -13¡F - 158¡F (-25¡C - 70¡C)
- Protection : Thermal Magnetic
Product Data
- UPC : 783643314870
- GTIN : 00783643314870
- Country of Origin : Mexico
- Dimensions : 4.724 x 0.787 x 5.906 inch
- Weight : 1.146
- Certification : Ul Listed, IEC
