ECC04C1A6A - Eaton C30CN Mechanically Held Lighting Contactor 30A 120V Six-Pole NEMA 1

ECC04C1A6A

ECC04C1A6A is an Eaton C30CN mechanically held lighting contactor designed for reliable control of lighting loads in industrial and commercial applications.

This non-combination contactor features mechanical holding with magnetic latching operation, providing dependable performance for tungsten lamp, ballast, and mercury vapor applications. The unit is housed in a painted steel NEMA 1 enclosure and is rated for 30 amperes at 480V for tungsten lamps and 600V for ballast or mercury vapor type applications. The contactor operates on 110-120 Vac coil voltage at 50/60 Hz and includes six poles for flexible circuit configuration.

Key Specifications

• Part Number: ECC04C1A6A
• Amperage Rating: 30A
• Contact Rating: 30A
• Coil Voltage: 110-120 Vac, 50/60 Hz
• Number of Poles: Six-pole
• Operation: Mechanically held, magnetically latched
• Enclosure Type: NEMA 1
• Enclosure Material: Painted steel
• Series: C30CN
• Certifications: UL Listed, cUL Listed
• Product Dimensions: 7.62 in (L) x 12.6 in (H) x 6 in (W)
• Product Weight: 13 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This Magnetically Latched includes a 110 VAC coil.

Specifications

• Part Number: ECC04C1A6A
• Manufacturer : Eaton
• Brand : Eaton
• Category : Motor Control
• Item Subcategory : Contactor
• Voltage : 2
• Compatible Frames : JDB,JD,HJD,JDC
• Frequency : 50 Hz

Product Data

• UPC : 782116156368
• GTIN : 00782116156368
• Country of Origin : United States
• Dimensions : 7.62 in x 12.6 in x 6 in (Length/Depth x Height x Width)
• Weight : 13
• Certification : UL Listed,cUL Listed
