DK3400W - Cutler Hammer 400A 240V 3-Pole DK Frame Molded Case Circuit Breaker 65kA Interrupt Rating

DK3400W

DK3400W is a 400 Amp, 3 Pole molded case circuit breaker from Cutler Hammer designed for 240 Volt applications with a DK frame style.This Cutler Hammer DK3400W circuit breaker features a thermal magnetic trip unit with long-time and instantaneous trip functions. It is a bolt-on type breaker with a 65 kiloampere interrupting rating at 240 VAC and 10 kiloampere at 250 VDC. The breaker is UL and CSA certified and does not include terminal lugs. It is part of the Series C frame and is suitable for industrial panel mount applications.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 400 A
• Voltage Rating: 240 VAC, 250 VDC
• Poles: 3
• Frame Type: DK
• Interrupting Rating: 65 kA @ 240 VAC, 10 kA @ 250 VDC
• Trip Unit: Thermal Magnetic, Fixed Trip
• Mounting Type: Bolt-On
• Certifications: UL, CSA, CE
• Standard Lug Type: Without Terminals
• Series: Series C
• Dimensions: Approx. 5.5" W x 5.5" H x 4.1" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

Lugs are not included

Specifications

• Part Number: DK3400W
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : DK
• Voltage : 240
• Amperage : 400
• Phase : 3
• Poles : 3
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• UPC : 786679044698
• GTIN : 00786679044698
• Country of Origin : Dominican Republic
• Dimensions : 4.1 in x 5.5 in x 5.5 in (Length/Depth x Height x Width)
• Weight : 11.4
• Certification : UL Listed
