CVS3125X - Cutler Hammer 125A 240V 3 Pole Molded Case Circuit Breaker CV Frame 42kAIC Bolt-On

CVS3125X

CVS3125X is a Cutler Hammer 3 pole molded case circuit breaker rated for 125 amps and 240 volts AC with a 42 kA interrupt rating.This Eaton Type CV circuit breaker features thermal magnetic trip units, bolt-on mounting, and is suitable for use as a main breaker. It supports wire sizes from #6 to 4/0 AWG aluminum or copper and has line and load side lug terminals. The breaker meets UL 489 and CSA C22.2 No. 5 certifications.

• Amperage: 125 A
• Voltage: 240 VAC
• Poles: 3
• Interrupt Rating: 42 kAIC
• Frame Type: CV
• Mounting Type: Bolt-On
• Wire Size Range: #6 - 4/0 AWG Cu/Al
• Trip Unit: Thermal Magnetic
• Terminals: Line & Load Side Lug
• Certifications: UL 489, CSA C22.2 No. 5
• Suitable for use as Main Breaker
• Manufacturer: Eaton (Cutler Hammer)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CVS3125X
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CVS Series
• Type : CVS
• Voltage : 240
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 25kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786685704234
• GTIN : 00786685704234
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.4
• Certification : UL 489,CSA Std. C22.2 No. 5
• Wire Size : #6 to 4/0 AWG Copper/Aluminum
