CV3175X - Cutler Hammer 175A 240V 3-Pole Molded Case Circuit Breaker Bolt-On CV Frame

CV3175X

CV3175X is a Cutler Hammer molded case circuit breaker designed for reliable protection in electrical systems.This 3-pole circuit breaker features a 175 ampere rating and operates at 240 volts AC. It uses a bolt-on mounting type and includes thermal magnetic trip protection. The breaker has a CV frame type with an interrupt rating of 65 kAIC, suitable for heavy-duty applications. It supports wire sizes from #6 AWG to 4/0 AWG copper or aluminum conductors. Certified to UL 489 and CSA C22.2 No. 5 standards, it offers a limited lifetime warranty.

Key Specifications
• Amperage: 175 A
• Voltage: 240 VAC
• Number of Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65 kAIC
• Frame Type: CV
• Trip Unit: Thermal Magnetic
• Wire Size Range: #6 AWG to 4/0 AWG Cu/Al
• Certifications: UL 489, CSA C22.2 No. 5
• Warranty: Limited Lifetime
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CV3175X
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CV Series
• Type : CV
• Voltage : 240
• Amperage : 175
• Phase : 3
• Poles : 3
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic



Product Data

• UPC : 78668570469
• GTIN : 00786685704692
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.4
• Certification : CSA Std. C22.2 No. 5,UL 489
• Wire Size : #6 to 4/0 AWG CU/AL
