CV3150X - Cutler Hammer Bolt-On 150 Amp 3 Pole Circuit Breaker

Save $5,588.71
SKU: CV3150X-New

Title: New
Sale price$1,009.81 Regular price$6,598.52
In stock, ready to be shipped

We also have No Box, Recertified, and Surplus options available.
Call (866) 377-3532 for a price!

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info



The Cutler Hammer CV3150X is a molded case circuit breaker. This type CV circuit breaker is a member of The CV series family. The CV3150X is a 3 pole, 240 Volt, 150 amp rated circuit breaker, with an AIC rating of 65kA@240V and is manufactured by Cutler Hammer. The CV3150X uses a bolt-on connection and includes thermal magnetic protection. The trip unit features LI - Long-Time and Instantaneous functions. Every part Essential Electric sells is also backed by our industry leading gold standard 2-year warranty.


  • Part Number: CV3150X
  • Manufacturers: Cutler Hammer
  • Sub-Category: Molded Case
  • GTIN: 00786685704685
  • Poles: 3
  • Phase: 3
  • Voltage: 240
  • Amperage: 150
  • AIC Rating: 65kA@240V
  • Connection: Bolt-On
  • Protection: Thermal Magnetic
  • Functions: LI - Long-Time and Instantaneous
  • Wire size: #6 to 4/0 AWG CU/AL
  • Family: CV Series
  • Type: CV
  • Certification: UL, CSA
  • Weight: 5
