CV3125X - Cutler Hammer 125A 240V 3 Pole Molded Case Circuit Breaker 65kA Interrupt Rating Bolt-On Frame CV

CV3125X

CV3125X is a Cutler Hammer molded case circuit breaker rated for 125 amps, 240 volts, and three poles with a 65kA interrupt rating.This CV series bolt-on circuit breaker features thermal magnetic trip units, suitable for 1-phase applications. It supports wire sizes from #6 to 4/0 AWG aluminum or copper conductors and offers a maximum load capacity of #4/0 kcmil. Certified to UL 489 and CSA C22.2 No. 5 standards, it provides reliable protection with a limited lifetime warranty.

• Amperage: 125 A
• Voltage: 240 VAC
• Poles: 3
• Interrupt Rating: 65 kAIC @ 240V
• Frame Type: CV
• Mounting Type: Bolt-On
• Trip Unit: Thermal Magnetic
• Wire Size Range: #6 - 4/0 AWG Al/Cu
• Certifications: UL 489, CSA Std. C22.2 No. 5
• Maximum Load: #4/0 kcmil
• Product Dimensions: 7.5 in depth, 5 in height, 5 in width
• Weight: 4.4 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CV3125X
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : CV Series
• Type : CV
• Voltage : 240
• Amperage : 125
• Phase : 3
• Poles : 3
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 78668570467
• GTIN : 00786685704678
• Country of Origin : Dominican Republic
• Dimensions : 7.5 in x 5 in x 5 in (Length/Depth x Height x Width)
• Weight : 4.4
• Certification : UL 489,CSA Std. C22.2 No. 5
• Wire Size : #6 to 4/0 AWG CU/AL
