CND412T33W - Eaton 1200A 600VAC 4-Pole NG-Frame Series C Electronic Molded Case Circuit Breaker Digitrip 310

CND412T33W

CND412T33W is an Eaton Series C electronic molded case circuit breaker designed for reliable power distribution protection.This circuit breaker features a 1200 ampere rating with a 600 VAC voltage rating and four poles. It is part of Eaton's NG-frame Series C line and includes a Digitrip 310 electronic long-time/short-time (LS) trip unit. The breaker is 80% rated and operates at 50/60 Hz frequency. It has an interrupt rating of 85 kAIC at 240 VAC and 50 kAIC at 480 VAC. The breaker comes without terminals and is HACR rated for HVAC applications.

Key Specifications
• Amperage: 1200 A
• Voltage: 600 VAC
• Number of Poles: 4
• Frame: NG
• Series: Series C
• Trip Unit: Digitrip 310 Electronic LS Trip
• Interrupt Rating: 85 kAIC at 240 VAC, 50 kAIC at 480 VAC
• Frequency: 50/60 Hz
• Mounting Type: Molded Case
• Rating: 80% rated
• Certifications: HACR Rated
• Terminals: Without terminals
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CND412T33W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CND
• Voltage : 600
• Amperage : 1200
• Phase : 3
• Poles : 4
• AIC rating : 50kA@480V
• Connection : Bolt-On
• Functions : LS - Long-Time and Short-Time
• Frame Size : N Frame
• Protection : Solid State



Product Data

• Country of Origin : United States
• Weight : 63 lb
