CKD3100X - Eaton Series C K-Frame 100 Amp 3 Pole 600V Molded Case Circuit Breaker

CKD3100X

CKD3100X is an Eaton Series C K-frame molded case circuit breaker designed for industrial and commercial power distribution applications.

This complete breaker assembly features a 100 ampere rating at 600 Vac/250 Vdc with fixed thermal and fixed magnetic trip protection. The 3-pole configuration supports three-phase power systems. The K-frame design provides compact mounting in standard electrical enclosures. Interrupt capacity reaches 65 kAIC at 240 VAC and 35 kAIC at 480 VAC, meeting demanding short-circuit protection requirements. The breaker operates at 50/60 Hz frequency and carries UL listing for compliance with UL 489 standards.

• Amperage Rating: 100 A
• Voltage Rating: 600 Vac, 250 Vdc
• Number of Poles: 3
• Frame Type: K-frame
• Series: C
• Trip Unit: Fixed Thermal/Fixed Magnetic (T186)
• Interrupt Rating: 65 kAIC at 240 VAC / 35 kAIC at 480 VAC
• Frequency: 50/60 Hz
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: CKD3100X
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CKD
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic

Product Data

• Dimensions : 4.31" X 10.13" X 5.5"
• Weight : 12 lb
