CKD3100W - Eaton 100A 600V 3-Pole Series C Molded Case Circuit Breaker

CKD3100W

CKD3100W is a 100 amp, 600 volt, 3-pole molded case circuit breaker from Eaton's Series C family designed for reliable circuit protection.This Eaton CKD3100W circuit breaker features a fixed thermal and fixed magnetic trip unit, suitable for industrial and commercial applications requiring robust overload and short circuit protection. It supports a 600 VAC and 250 VDC voltage rating and offers interrupt ratings of 65 kA at 240 VAC and 35 kA at 480 VAC, ensuring high fault current interruption capability.

Key Specifications
• Amperage: 100 A
• Voltage Rating: 600 VAC, 250 VDC
• Poles: 3
• Series/Frame: Series C, K-Frame
• Trip Unit: Fixed Thermal / Fixed Magnetic
• Interrupt Rating: 65 kA at 240 VAC, 35 kA at 480 VAC
• Mounting Type: Fixed
• Phase: 3
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: CKD3100W
• Manufacturer : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : CKD
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Frame Size : K Frame
• Protection : Thermal Magnetic



Product Data

• Dimensions : 10.31" X 5.5" X 4.31"
• Weight : 12 lb
