Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
CHND212T35W
CHND212T35W is an Eaton Series C electronic molded case circuit breaker designed for reliable protection in demanding electrical environments. This NG-frame breaker features a two-pole configuration, 1200A amperage rating, and 600V voltage rating, making it suitable for a wide range of industrial and commercial applications. The breaker is equipped with a Digitrip 310 RMS electronic LSG trip unit for precise protection and monitoring. The CHND212T35W is engineered for high interrupt capacity, supporting up to 100 kAIC at 240 Vac and 65 kAIC at 480 Vac. It is designed for use in systems operating at 50 to 60 Hz and is UL Listed for safety and compliance. The breaker is supplied without terminals, allowing for flexible installation options.
- Part Number: CHND212T35W
- Manufacturer: Eaton
- Series: Series C
- Frame: NG
- Amperage Rating: 1200 A
- Voltage Rating: 600 Vac
- Number of Poles: Two-pole
- Interrupt Rating: 100 kAIC at 240 Vac, 65 kAIC at 480 Vac
- Frequency Rating: 50 to 60 Hz
- Terminals: Without terminals
- Trip Type: Electronic LSG
- Certifications: UL Listed
Specifications
- Part Number: CHND212T35W
- Manufacturer : Eaton
- Brand : Culter Hammer
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Series C
- Type : CHND
- Voltage : 600
- Amperage : 1200
- Phase : 1
- Poles : 2
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LSG - Long-Time, Short-Time and Ground Fault
- Frame Size : N Frame
- Protection : Solid State
Product Data
- Weight : 42
